B·H series aims to provide a professional yet efficient sonic performance to all kind of users, combining an extremely efficient CLASS D amplifier with aggressive sound pressure levels (up to 126,5 dB for the 15” cabinet), while delivering the most accurate sound reproduction. The active two-way speaker series providing a professional sonic performance to all kind of users. The most accurate sound reproduction combined with aggressive sound pressure levels and enhanced portability. Specifications Maximum efficiency up to 126.5 dB SPL Professional acoustic performance Innovative horn design for uniform and extended coverage Compact featherweight Clean and contemporary design enhancing portability 3 handles Double stage monitor angle Preset EQ Flat /Boost Speaker Type 2-Way Active Speaker Usable Bandwidth [-10dB] 51 – 20.000 Hz Frequency Response [-6 dB] 57 – 19.700 Hz Max SPL 126.5 dB Type HF Compression Driver HF voice coil 1″ LF 15″ LF voice coil 2″ Crossover Frequency 2100 Hz (24 dB/oct.) Horizontal Dispersion asymmetrical 85° up / 120°down Vertical Dispersion 85° ( 25/ -60°) Amp Technology Custom Made Amp Class Class D – Passice cooling (convection) Power Peak 400 W Controller DSP 28/56 bit- 48 kHz Limiter Peak, RMS, Thermal Controls Volume, Audio Input Sensitivity, DSP Preset Main Connection VDE Signal Input Balanced 1xCombo IN (MIC/LINE) SIGNAL Out (Balanced) 1xXLR OUT (LINK) Housing Polypropylene Grille Full Metal Grille Handles 3 (2 on side 1 on top) Pole Mount 36 mm Width 41.5 cm Height 72.5 cm Depth 39.1 cm Weight 17.4 kg Categories: Active Speakers, Sound, Speakers
